Door top open aluminium extrusion die preheater

Door top open aluminium extrusion die preheater

Die oven use infrared heating structure, energy saving, high efficiency, low consumption
Before extrusion, the die of profile must be preheating, after heating and keeping temperature, send to extrusion press.
Adopts drawer type, side opening door, one working chamber. Use crane to carry mould, before put mould, manually open oven door through pneumatic cylinder, then put mould inside of chamber, close door, start electricity heating system, then start heat-up(must preheating chamber when first time heating mould). After reaching sized value of temperature(normally it is 480ºC), keep heating, then open furnace door, draw out mould to send for extrusion press.
Infrared die oven use several carbon electricity rods to heat, play a part in high efficiency, energy saving features. At the back of carbon rods, there is infrared radiation plate, which can radiate to furnace chamber. Heating body is made of radiation plate and carbon rods, through radiation to transfer energy to furnace chamber, steel suction energy , then transfer magnetic energy to another heating method, during heating, reducing thermal pressure of steel, thermal exhaustion of temperature changing, also reducing thick parcel and carbon-removing because of oxidation for steel.
